Download
VDS
V
VGS
V
ID
A
VGS(TH)
V
RDS(mΩ)@VGS
10V Typ
RDS(mΩ)@VGS
10V Max
RDS(mΩ)@VGS
4.5V Typ
RDS(mΩ)@VGS
4.5V Max
-
CH20NP04H
Single-N+P
±40
±20
10/-7
2.5
12
18
16
24
SOP-8
-
CH2460SN
Single-N+P
±60
±20
30/-36
2.5
24
35
30
40
DFN5×6
-
CH30NP04SN
Single-N+P
±40
±20
30/-20
2.0
14
18
17.8
19
DFN5×6
-
CH1030SN
Single-N+P
±30
±20
±30
2
10
12
14.5
19
DFN5×6
-
CH30NP03SN
Single-N+P
±30
±20
30/-25
2.0
10
12
15.5
19
DFN5×6
-
CH20NP06SN
Single-N+P
±60
±20
20/-10
2.5
24
35
30
40
DFN3×3
-
CH60NP03SN
Single-N+P
±30
±20
30/-25
2.0
10
12
15.5
19
DFN3×3
-
CH5NP03SQ
Single-N+P
±30
±12
5.8/-4.2
1.5
-
65
-
75
SOT23-6
-
CH30P03SN
Single-P+P
-30
±20
-30
-2.5
-18
-25
-28
-38
DFN3×3
-
CH20N06SN
Single-N+N
60
±20
20
2.5
26
33
33
45
DFN3×3
-
CH60N03SN
Single-N+N
30
±20
40
3.0
6.5
8
9
14
DFN3×3
